MEP dedusting cassette filter

mep-mep-ex-immagine-220301174028.i3387-kw9EXKV-l1-1

The compact and reliable dedusting cassette filter

SO.TEC's range of dust extraction equipment includes highly efficient solutions for industrial dust extraction.

MEP filter it's a dust extractor for small and medium-sized activities, equipped with special cassette filters for dust removal and collection of dust components. The system is modular according to requirements and can be enhanced by a full range of accessories.

Continuous and safe operation of the dedusting plant is a prerequisite for constant production.

MEP filter is a competitive industrial dust collector ready to meet various needs with both flexible installation and effective and safe filtration.

Compact with high performance

MEP filter is developed to provide maximum filtration efficiency with a very small footprint. The dust collector can thus be installed close to where the dust is generated. This means less energy consumption, less piping and ultimately lower installation cost.

Of course, the filter can also be installed outdoors. Maintenance can be carried out from floor level due to the compact construction, which often eliminates the need for walkways and other structures.

Filter characteristics

MEP filters can be produced with modules of 2, 4, 6 or 8 cassettes (15 to 88 m²) and with expandable capacities of up to 10.500 m³/h.
Integrated fans from 3kW to 18.5kW positioned above the filter.
High-efficiency, automatic, counterflow, compressed air cleaning system.
Wide range of filter fabrics. Wide range of accessories, including fans, support structures, walkways, valves, dust collection bins, silencers, protective elements for abrasive dusts and fast-closing inspection doors.
3 main types:
- Filter with open base flange for "silo type" connection
- Filter with hopper and flange
- Filter with hopper and collection bin.
Possibility of indoor and outdoor installation.

The MEP series filter is also produced in an ATEX certified version for dusts with an explosion hazard class rating of St-1, St-2 and St-3.

Filtri MEP 8 -4-6 per aspirazione polveri pulitura acciaio

Filtro MEP depolveratore per rifinitura articoli in gomma

Filtro depolveratore MEP sabbiatura metalli

Filtro depolveratore per resine inerti e zirconio

3 Filtri depolveratori per sabbiatura ottone

Filtro MEP per lavorazione meccanica a secco di ghisa

Filtro depolveratore per smerigliatura automatica di ottone

Filtro depolveratore per smerigliatura di ottone

Filtri depolveratori per polveri da pulitura e smerigliatura ottone 2

Filtro depolveratore - produzione anime fonderia

Filtri depolveratori per polveri da pulitura e smerigliatura ottone

Filtro MEP depolveratore per taglio barre ottone

Application fields

pulitura-metalli-140530181006.i211-k28sftw-w380-h255-f1-l1-c1

Metal cleaning and grinding

Grinding and polishing are mechanical surface finishing operations. These particular finishing operations take place...

granigliatura-140604121450.i462-kCo01Rg-w380-h255-f1-l1-c1

Shot blasting

Shot blasting is a method used to clean, strengthen (peen) or polish metal materials. Shot blasting is typically performed upon steel cast iron and metal...

burattatura-140530181022.i209-kSdHe4W-w380-h255-f1-l1-c1-1

Dry tumbling

Dry tumbling is a mechanical surface finishing process. It is typically used for the mechanical removal of substrate residues...

sabbiatura-140508100539.i215-kfOtmYo-w380-h255-f1-l1-c1

Metal sandblasting

Sandblasting is a process by which the exterior or surface portion of a material is eroded via an abrasion generated by a jet of sand...

chimico-farmaceutico-140508100720.i216-kEmglpy-w380-h255-f1-l1-c1

Chemical-Pharmaceutical

Various stages of the chemical and pharmaceutical processes generate dusts that need to be properly captured and filtered...

alimentare-2-140508105956.i225-kWiGh12-w380-h255-f1-l1-c1

Food processing

In food processing, combustible dust is a hidden but ever-present hazard. The various processes of grinding, crushing, mixing and packaging generate small particles that may appear harmless...
